DLA-X90R/X70R Screen Adjustment Mode Table

Company	Screen	Mode
-	-	1*
	-	2*
	-	3*
CARADA	Classic Cinema White	4
	Brilliant White	5
	High Contrast Gray	6
DA-LITE	MATTE WHITE	7
	HIGH CONTRAST MATTE WHITE	8
	VIDEO SPECTRA 1.5	9
	SILVER MATTE	10
	HIGH POWER	11
	DA-MAT	12
	HIGH CONTRAST DA-MAT	13
	CINEMA VISION	14
	HIGH CONTRAST CINEMA VISION	15
	PEARLESCENT	16
	DUAL VISION	17
	AUDIO VISION	18
	HIGH CONTRAST AUDIO VISION	19
	HIGH CONTRAST CINEMA PERL	20
	3D VIRTUAL GREY	21
	HD PROGRESSIVE 0.6	22
	HD PROGRESSIVE 0.9	23
DRAPER	FLEXABLE MATTE WHITE	24
	FIBERGLASS MATTE WHITE	25
	HIGH CONTRAST GREY	26
	FLEXIBLE M 1300	27
	HIGH DEF GREY	28
	M 2500	29
EASTONE	E2S	30
	ESECO	31
	BF-3D Reference	96
KIKUCHI	WA	32
	AM	33
	AG	34
	PG	35
	MALIBU	36
	GRACE MATT 100	101
GRANDVIEW	GRANDVIEW WHITE	37
ORAY	B3100100	38
	B1100100 32/100	39
	B1100100 25/100	40
	BC100100	41
	N3100100 MICROPERF	42
	N3100100 SUPER BLANC	43
OS	WG103	44
	WG107G	45
	WG201	46
	WG206	47
	WG207	48
	WT101	49
	WF201	50
	WF202	51
	WF203	95
	サニーホワイト	52
	BS101	53
	BU102	54
	PP201	55
	BU202	94
PROCOLOR	MATTE WHITE C	56
PROCOLOR	MATTE WHITE P	57
SCREEN RESEARCH	ClearPix2	58
SI	Lunar HD.85	59
	Solar HD1.3	60
	Gamma HD1.1	61
	Gamma Maestro HD1.1	62
	Lunar Maestro HD.85	63
	Black Diamond II HD0.8	64
	Black Diamond II HD1.4	65
Stewart	SnoMatte 100	66
	Ultramatte 130	67
	Ultramatte 150	68
	Ultramatte 200	69
	StudioTek 100	70
	StudioTek 130 G3	71
	GrayMatte 70	72
	FireHawk SST	73
	FireHawk G3	74
	GrayHawk RS	75
	SILVER 3D	97
	SILVER 5D	98
	Reflections Active 170 3D	99
STUMPFL	FLEX WHITE CI	100
Theaterhouse	ホワイトマット	76
Theaterhouse	シアターマット	77
VUTEC	MATTEWHITE	78
	BRIGHT WHITE	79
	VUFLEX PRO	80
	PEARL BRIGHT	81
	GREYDOVE	82
	SOUND SCREEN-5	83
	SOUND SCREEN-15	84
	GREYDOVE SOUND SCREEN	85
	TWIN VU	86
	PREFORATED LEADER	87
	SILVER STAR	88
ELITE	CineWhite	89
	PowerGain	90
	Elite MaxWhite	91
	MaxWhite FG	92
	SilverGrey	93

* If none of the above applies,please select from 0 to 3
- 0:OFF
- 1:Correct to give a reddish tinge
- 2:Correct to give a greenish tinge
- 3:Correct to give a bluish tinge
*The Screen Adjustment Mode Table is that recommended by JVC.
*The exact results from any given the Screen Adjustment Mode Table will be affected to some degree by the installation environment, so this table should be used only as a guide.
*The mode used for any given screen is not a reflection of the quality of the screen.

DLA-X30 Screen Adjustment Mode Table

Company	Screen	Mode
CARADA	Classic Cinema White	A
	Brilliant White	OFF
	High Contrast Gray	OFF
DA-LITE	MATTE WHITE	OFF
	HIGH CONTRAST MATTE WHITE	OFF
	VIDEO SPECTRA 1.5	OFF
	SILVER MATTE	A
	HIGH POWER	OFF
	DA-MAT	A
	HIGH CONTRAST DA-MAT	B
	CINEMA VISION	C
	HIGH CONTRAST CINEMA VISION	OFF
	PEARLESCENT	C
	DUAL VISION	A
	AUDIO VISION	A
	HIGH CONTRAST AUDIO VISION	B
	HIGH CONTRAST CINEMA PERL	OFF
	3D VIRTUAL GREY	A
	HD PROGRESSIVE 0.6	A
	HD PROGRESSIVE 0.9	A
DRAPER	FLEXABLE MATTE WHITE	A
	FIBERGLASS MATTE WHITE	A
	HIGH CONTRAST GREY	A
	FLEXIBLE M 1300	A
	HIGH DEF GREY	A
	M 2500	C
EASTONE	E2S	OFF
	ESECO	A
	BF-3D Reference	OFF
KIKUCHI	WA	A
	AM	B
	AG	A
	PG	A
	MALIBU	OFF
	GRACE MATT 100	OFF
GRANDVIEW	GRANDVIEW WHITE	A
ORAY	B3100100	A
	B1100100 32/100	OFF
	B1100100 25/100	OFF
	BC100100	A
	N3100100 MICROPERF	OFF
	N3100100 SUPER BLANC	OFF
OS	WG103	A
	WG107G	C
	WG201	A
	WG206	OFF
	WG207	OFF
	WT101	OFF
	WF201	A
	WF202	A
	WF203	OFF
	サニーホワイト	OFF
	BS101	OFF
	BU102	OFF
	PP201	C
	BU202	A
PROCOLOR	MATTE WHITE C	OFF
PROCOLOR	MATTE WHITE P	OFF
SCREEN RESEARCH	ClearPix2	OFF
SI	Lunar HD.85	OFF
	Solar HD1.3	OFF
	Gamma HD1.1	OFF
	Gamma Maestro HD1.1	OFF
	Lunar Maestro HD.85	OFF
	Black Diamond II HD0.8	A
	Black Diamond II HD1.4	A
Stewart	SnoMatte 100	OFF
	Ultramatte 130	OFF
	Ultramatte 150	OFF
	Ultramatte 200	C
	StudioTek 100	OFF
	StudioTek 130 G3	OFF
	GrayMatte 70	A
	FireHawk SST	A
	FireHawk G3	A
	GrayHawk RS	A
	SILVER 3D	OFF
	SILVER 5D	OFF
	Reflections Active 170 3D	A
STUMPFL	FLEX WHITE CI	OFF
Theaterhouse	ホワイトマット	A
Theaterhouse	シアターマット	A
VUTEC	MATTEWHITE	A
	BRIGHT WHITE	A
	VUFLEX PRO	OFF
	PEARL BRIGHT	OFF
	GREYDOVE	A
	SOUND SCREEN-5	OFF
	SOUND SCREEN-15	A
	GREYDOVE SOUND SCREEN	A
	TWIN VU	A
	PREFORATED LEADER	A
	SILVER STAR	OFF
ELITE	CineWhite	A
	PowerGain	C
	Elite MaxWhite	OFF
	MaxWhite FG	OFF
	SilverGrey	OFF

*The Screen Adjustment Mode Table is that recommended by JVC.
*The exact results from any given the Screen Adjustment Mode Table will be affected to some degree by the installation environment, so this table should be used only as a guide.
*The mode used for any given screen is not a reflection of the quality of the screen.

DLA-X9/X7 Screen Adjustment Mode Table

Company	Screen	Mode
-	-	0
-	-	1*
-	-	2*
-	-	3*
CARADA	Classic Cinema White (Gs 1.0)	4
	Brilliant White (Gs 1.4)	5
	High Contrast Gray (Gs 0.8)	6
DA-LITE	MATTE WHITE	7
	HIGH CONTRAST MATTE WHITE	8
	VIDEO SPECTRA 1.5	9
	SILVER MATTE	10
	HIGH POWER	11
	DA-MAT	12
	HIGH CONTRAST DA-MAT	13
	CINEMA VISION	14
	HIGH CONTRAST CINEMA VISION	15
	PEARLESCENT	16
	DUAL VISION	17
	AUDIO VISION	18
	HIGH CONTRAST AUDIO VISION	19
	HIGH CONTRAST CINEMA PERL	20
	3D VIRTUAL GREY	21
	HD PROGRESSIVE 0.6	22
	HD PROGRESSIVE 0.9	23
DRAPER	FLEXABLE MATTE WHITE	24
	FIBERGLASS MATTE WHITE	25
	HIGH CONTRAST GREY	26
	FLEXIBLE M 1300	27
	HIGH DEF GREY	28
	M 2500	29
EASTONE	E2S	30
EASTONE	ESECO	31
KIKUCHI	（WA）	32
	（AM)	33
	(AG)	34
	(PG)	35
	MALIBU	36
GRANDVIEW	GRANDVIEW WHITE	37
ORAY	B3100100	38
	B1100100 32/100	39
	B1100100 25/100	40
	BC100100	41
	N3100100 MICROPERF	42
	N3100100 SUPER BLANC	43
OS	WG103	44
	WG107G	45
	WG201	46
	WG206	47
	WG207	48
	WT101	49
	WF201	50
	WF202	51
	SunnyWhite	52
	BS101	53
	BU102	54
	PP201	55
	BU202	94
PROCOLOR	MATTE WHITE C	56
PROCOLOR	MATTE WHITE P	57
SCREEN RESEARCH	ClearPix2	58
SI	Lunar HD.85	59
	Solar HD 1.3	60
	Gamma HD 1.1	61
	Gamma Maestro HD1.1	62
	Lunar Maestro HD.85	63
	Black Diamond ⅡHD0.8 Black	64
	Black Diamond ⅡHD1.4 Black	65
Stewart	SnowMatte 100	66
	Ultramatte 130	67
	Ultramatte 150	68
	Ultramatte 200	69
	StudioTek 100	70
	StudioTek 130 G3	71
	GrayMatte 70	72
	FireHawk SST	73
	FireHawk G3	74
	GrayHawk RS	75
Theater House	TeaterMatte	76
Theater House	WhiteMatte	77
VUTEC	MATTEWHITE	78
	BRIGHT WHITE	79
	VUFLEX PRO	80
	PEARL BRIGHT	81
	GREYDOVE	82
	SOUND SCREEN-5	83
	SOUND SCREEN-15	84
	GREYDOVE SOUND SCREEN	85
	TWIN VU	86
	PREFORATED LEADER	87
	SILVER STAR SURFACE	88
ELITE	CineWhite	89
	PowerGain	90
	Elite MaxWhite	91
	MaxWhite FG	92
	SilverGrey	93

* If none of the above applies,please select from 0 to 3
- 0:OFF
- 1:Correct to give a reddish tinge
- 2:Correct to give a greenish tinge
- 3:Correct to give a bluish tinge
*The Screen Adjustment Mode Table is that recommended by JVC.
*The exact results from any given the Screen Adjustment Mode Table will be affected to some degree by the installation environment, so this table should be used only as a guide.
*The mode used for any given screen is not a reflection of the quality of the screen.

DLA-X3/HD950/HD550 Screen Adjustment Mode Table

Company	Screen	Mode
CARADA	Classic Cinema White (Gs 1.0)	A
	Brilliant White (Gs 1.4)	OFF
	High Contrast Gray (Gs 0.8)	OFF
DA-LITE	MATTE WHITE	OFF
	HIGH CONTRAST MATTE WHITE	OFF
	VIDEO SPECTRA 1.5	OFF
	SILVER MATTE	A
	HIGH POWER	OFF
	DA-MAT	A
	HIGH CONTRAST DA-MAT	B
	CINEMA VISION	C
	HIGH CONTRAST CINEMA VISION	OFF
	PEARLESCENT	C
	DUAL VISION	A
	AUDIO VISION	A
	HIGH CONTRAST AUDIO VISION	B
	HIGH CONTRAST CINEMA PERL	OFF
	3D VIRTUAL GREY	A
	HD PROGRESSIVE 0.6	A
	HD PROGRESSIVE 0.9	A
DRAPER	FLEXABLE MATTE WHITE	A
	FIBERGLASS MATTE WHITE	A
	HIGH CONTRAST GREY	A
	FLEXIBLE M 1300	A
	HIGH DEF GREY	A
	M 2500	C
EASTONE	E2S	OFF
EASTONE	ESECO	A
KIKUCHI	（WA）	A
	（AM)	B
	(AG)	A
	(PG)	A
	MALIBU	OFF
GRANDVIEW	GRANDVIEW WHITE	A
ORAY	B3100100	A
	B1100100 32/100	OFF
	B1100100 25/100	OFF
	BC100100	A
	N3100100 MICROPERF	OFF
	N3100100 SUPER BLANC	OFF
OS	WG103	A
	WG107G	C
	WG201	A
	WG206	OFF
	WG207	OFF
	WT101	OFF
	WF201	A
	WF202	A
	SunnyWhite	OFF
	BS101	OFF
	BU102	OFF
	PP201	C
	BU202	A
PROCOLOR	MATTE WHITE C	OFF
PROCOLOR	MATTE WHITE P	OFF
SCREEN RESEARCH	ClearPix2	OFF
SI	Lunar HD.85	OFF
	Solar HD 1.3	OFF
	Gamma HD 1.1	OFF
	Gamma Maestro HD1.1	OFF
	Lunar Maestro HD.85	OFF
	Black Diamond ⅡHD0.8 Black	A
	Black Diamond ⅡHD1.4 Black	A
Stewart	SnowMatte 100	OFF
	Ultramatte 130	OFF
	Ultramatte 150	OFF
	Ultramatte 200	C
	StudioTek 100	OFF
	StudioTek 130 G3	OFF
	GrayMatte 70	A
	FireHawk SST	A
	FireHawk G3	A
	GrayHawk RS	A
Theater House	TeaterMatte	A
Theater House	WhiteMatte	A
VUTEC	MATTEWHITE	A
	BRIGHT WHITE	A
	VUFLEX PRO	OFF
	PEARL BRIGHT	OFF
	GREYDOVE	A
	SOUND SCREEN-5	OFF
	SOUND SCREEN-15	A
	GREYDOVE SOUND SCREEN	A
	TWIN VU	A
	PREFORATED LEADER	A
	SILVER STAR SURFACE	OFF
ELITE	CineWhite	A
	PowerGain	C
	Elite MaxWhite	OFF
	MaxWhite FG	OFF
	SilverGrey	OFF

*The Screen Adjustment Mode Table is that recommended by JVC.
*The exact results from any given the Screen Adjustment Mode Table will be affected to some degree by the installation environment, so this table should be used only as a guide.
*The mode used for any given screen is not a reflection of the quality of the screen.
